Sai ovislink krypton c60 chasis 60 kva trifasico sin baterias

Capacity 10 - 200kva

main input

input voltage pulgadas380v - 400v - 415v(line to line)220v - 230v - 240v(line to neutral)pulgadas

input frequency 50 - 60hz

power factor >0.99

input voltage window - 40%~+25%

frequency window 40 - 70hz

battery
battery voltage ±240vdc

charger power 20%*power

charger voltage precisión 1%

bypass
bypass voltage pulgadas380v - 400v - 415v - three phase220v - 230v - 240v - one phasepulgadas

bypass voltage window - 20% - +15% - full load - settable

bypass overload capabiltiy 125% - long time operatión

125%< load <130% - last for more than 1 hour

130%
>1000% - last for more than 100ms

output
output voltage pulgadas380v - 400v - 415v - three phase220v - 230v - 240v - one phasepulgadas

voltage precisión ±0.5% (balance load) -±1% (unbalance load)

voltage thd(total harmonic distortión) thd<1%(linear load) -thd<5%(nonlinear load)

power factor 0.8

phase tolerance 120°±0.5° (balance and unalance load)

crest factor 3:1

overload capabiltiy 105% -long time operatión

110% - transfer to bypass after 1hour

125% - transfer to bypass after 10 minutes

150% - transfer to bypass after 1 minute

>150% - transfer to bypass after 200ms

system
system efficiency normal mode: 95%

eco mode: 99%

battery mode efficiency 95%

display lcd+led - touch screen and keyboard

ip class ip20
interface (communicatión ports ) rs232 -rs485 -dry contacts -snmp card -epo -generator
interface
installatión - connectión top or bottom cable connectión

operatión temperature 0 - 40

storage temperature - 25~70

relative humidity 0 - 95% (non - comdensing)

noise(db) <55db
weight(kg) 6 - module cabinet rm060 - 10 - rm090 - 15 - rm120 - 20
150kg
10 - module cabinet rm100 - 10 - rm150 - 15 - rm200 - 20
180kg
pm10 10kva: 20kg

pm15 15kva: 21kg

pm20 20kva: 22kg

dimensión(w*d*h)(mm) 6 - module cabinet 600*900*1600

10 - module cabinet 600*900*2000

module 400*600*133 (10kva - 15kva - 20kva)
